Nano ITX Mini PC Intel Core 11th gen i5 i7 i9

Quick Details:

CPUIntel Core i5/i7/i9Storage2*M.2 2280
RAM2*SODIMMNetwork2*RJ45 Realtek 8111H
BIOSAMI EFI BIOSOSWin10/11, Linux
MaterialAluminum AlloyPower SupplyDC 12V

Feature


  • Optional Intel® Core 7gen,8gen,10gen,11gen of i5/i7/i9 CPU

  • 2x DDR4L SODIMM slot, supports up to 64GB

  • DP+HDMI dual display, synchronous/asynchronous mode

  • Dual storage, 1*M.2 2280 SATA,1*M.2 2280 NVMe

  • Low power consumption, ultra-quiet heat dissipation

  • Industrial grade working temperature -20℃~70℃


Specification

Model: SM06
PC
CPU OptionalIntel® Core i5-7300HQ, 4 Cores, 4 Threads, Base 2.5GHz, Turbo 3.5GHz
CPU OptionalIntel® Core i7-8850H, 6 Cores, 12 Threads, Base 2.2GHz, Turbo 4.1GHz
CPU Optionalntel® Core i7-9750H, 6 Cores, 12 Threads, Base 2.6GHz, Turbo 4.5GHz
CPU OptionalIntel® Core i9-9880H, 8 Cores, 16 Threads, Base 2.3GHz, Turbo 4.8GHz
CPU OptionalIntel® Core i5-10200H, 4 Cores, 8 Threads, Base 2.4GHz, Turbo 4.1GHz
CPU OptionalIntel® Core i9-10885H, 8 Cores, 16 Threads, Base 2.4GHz, Turbo 5.3GHz
CPU OptionalIntel® Core i7-1065G7, 4 Cores, 8 Threads, Base 1.3GHz, Turbo 3.9GHz
CPU OptionalIntel® Core i3-1115G4, 2 Cores, 4 Threads, Base 1.7GHz, Turbo 4.1GHz
CPU OptionalIntel® Core i7-1185G7/1195G7, 4 Cores, 8 Threads, Base 2.8GHz, Turbo 4.8GHz
Memory2x DDR4L SODIMM slot, supports up to 64GB
Storage1xM.2 2280 SATA, 1xM.2 2280 NVMe
1x HDD/SSD
Display1x DP, 2x HDMI, (Support synchronous display or asynchronous display)
Network2 x GbE RJ45 Realtek 8111H
I/O4x USB3.0, 2 x USB2.0
1x Audio Line-out, 1 x Audio Mic-in
1x Power Button
1x Power input
1x DP, 1xHDMI
Expansion SlotMini-PCIe x 1 half card, support WIFI Bluetooth
BIOSAMI EFI BIOS
WDT Support hardware reset (256 level, 0-255 sec)
Operation SystemWindows® 7 /8/10, WES 7,LINUX
Power Supply
External Power SupplyAC 100 - 240V
Working voltageDC 12V
Power consumption≤15W
Enclosure
MaterialAluminum Alloy
ColorBlack
Operating Environment
Temperature RangeOperating: -20 to 70°C, Storage: -30 to 80°C,  surface air flow
Relative humidity0%~95% , non-condensing
Packing Details
Net weight0.7 kg
Gross weight1.5 kg
Product Dimension150 x 135x66 mm
Packing size30*20*12cm
AccessoriesPower adapter, Driver CD, 2.5-inch hard drive bracket, Screws
Other
Mounting (options)Wall mounting
Desktop installation
Warranty2 years warranty






Nano ITX Mini PC Intel Core i7 1185G7E Dual HDMI
