Feature
High Temperature Tolerance
Even without a fan, Industrial Computer Rugged products can operate in temperatures from -20 to 60˚C in the field.
Multi Screen Display
Support synchronous and asynchronous three display.1*HD+2*DP, Max Resolution support 4096x2160 @ 60Hz.
Watchdog Timer Utility
Available on Industrial Computer, this utility monitors and restarts an unresponsive application or OS, protecting the end user experience.
Mounting Options
The Industrial Computer chassis offers multiple mounting options, including VESA, and wall mounting.
24/7 Operation
Industrial Computer are built to last and qualified for 24/7 sustained operations - a must-have for commercial and industrial use cases.
Wide Voltage Optional
Industrial Computer feature 12v to 24v DC input with overvoltage protection and dirty DC tolerance.
Specification
Model: SM1021 | |
PC | |
CPU | Onboard Intel Celeron J4125（Quad core quad threading，4MB cache，2.0GHz，Max turbo 2.7GHz） |
BIOS | AMI EFI BIOS |
CPU Architecture | Gemini Lake Refresh |
RAM | Support 1*DDR4 2400MHz SODIMM RAM Slot，MAX 8GB |
Storage | 1*M.2 2280 Slot，Onboard 1*2.5”HDD |
Display Chip | Integrated Intel HD Graphics Card 600 |
Display Interface | 1*HDMI，2*DP（Support synchronous and asynchronous three display，Max Resolution support 4096x2160 @ 60Hz） |
Front I/O | 1*Power Switch，4*USB3.0，2*USB2.0，1*COM |
Rear I/O | 1*DC，1*HDMI，2*DP，2*Intel 1000M LAN，1*SIM Card Slot，1*Audio (support audio and mic input) |
Network Card | 2*10/100/1000M RTL8111H Ethernet Lan |
Expansion | Support 1*M.2 2280 M-key Slot（Support SATA） |
Support 1*M.2 2242 B-key Slot（Support4G），Embedded SIM slot | |
Support 1*M.2 2230 E-key Slot（Support WIFI、BT） | |
Expansion function: TPM Pin (support TPM 1.2 / 2.0 security module)，1*COM | |
Other Function | Auto power on when there is electricity、Timing boot、Wake on LAN、PXE boot |
Power Supply | Support DC 12 Input |
Operating Environment | |
Work Temp | 0℃ ～ +50℃（Commercial HDD），-20℃ ～ +60℃（Industrial SSD），Surface air flow |
Work Humidity | 0% ～ 95% non-condensing |
Packing Details | |
Cetificates | CE, CCC, FCC Class A, ROHS |
Dimension | 144 * 126.5 * 42 mm (L*W*H); |
Net Weight | 0.8 kg |
Application | Industrial Automation, Medical, Logistics Transportation, Warehouse, Electronic Education, etc. |
Enclosure | |
Case Color | Black (any color can be customized) |
Material | High quality all aluminum alloy mini itx case |
Other | |
Mounting (options) | 1) provide wall brackets for wall-mounting, VESA 100×100mm |
2) provide stable metal holder to support the monitor | |
Customization | 3G,4G,Webcam, RFID reader etc. optioanal |
Warranty | 3 year warranty |
