Features:
Based on Intel Alder/Raptor Lake desktop platform;
Adopt ATX motherboard size specification;
Dual network ports, support 2.5Gbps
2*PCIe-X16/4*PCIe-X4/1*PCI;
NVIDIA T1000 8GB independent graphics card, 4 mini DP interfaces
Aluminum alloy shell anti-ultraviolet and anti-discoloration treatment
Specification
| PC | |
| CPU | CPU: Intel® Core i5-12400, 6 Cores, 12 Threads, Turbo 4.4 GHz, Fan |
| Chipset | Intel Q670/H610 |
| Memory | 4x DDR5 288-PIN DIMM |
| Storage | Onboard 4*SATA3.0 interfaces, support Raid 0/1/5/10 2*M.2 2280 M-Key（NVME/SATA3.0） |
| Graphics | NVIDIA T1000 8GB |
| Audio | ALC897 |
| Network | 2*LAN, LAN1 uses Intel I219LM, LAN2 uses Intel I226-V, supports 2.5Gbps |
| Wireless | WIFI/Bluetooth, 4G Optional |
| BIOS | AMI EFI BIOS |
| WDT | Support hardware reset (256 level, 0-255 sec) |
| Operation System | Support Windows 7/8/10, Linux, Ubuntu, Debian etc. |
| Other | Power-on, timed power-on, network wake-up, PXE boot, watchdog (level 0 to 255) |
| I/O | |
| Front I/O | 1x PS/2 2x USB2.0 1x DP 1x HDMI 1x VGA 1x RS232 2x USB3.1 4x USB3.0 2x LAN 1x LINE-IN 1x LONE-OUT 1x MIC-IN 1x AC110-240V 4x MINI DP 1x Power on/off button |
| Rear I/O | 4x COM RS232 |
| Power Supply | |
| Working voltage | AC100-240V |
| Power consumption | 250W |
| Enclosure | |
| Material | Aluminum alloy baffle + galvanized cold-rolled sheet shell |
| Color | Black |
| Cooling system | Active - Fan |
| Operating Environment | |
| Temperature Range | Operating: -10 to 60°C, storage: -20 to 70°C |
| Relative humidity | Up to 90% at all relevant temperatures |
| Vibration | GB/T 2423.10-2019 |
| Shock | GB2423.5 |
| EMC | Class B |
| Packing Details | |
| Product weight | Net weight 7.8 |
| Product dimension | 402.3*295.76*162.18mm |
| Packing info | 1pcs/ctn 66×24×48cm 12kg |
| Accessories | Power cord, power adapter, mounting edge strip, mounting screws |
| Other | |
| Warranty | 2 years warranty |
| Certificates | CE, FCC, RoHS |
