Premium Industrial-Grade Touch Display with Advanced Environmental Protection
Engineered with a robust aluminum alloy enclosure featuring IP65-certified waterproof and dustproof protection on the front panel, ensuring reliable operation in demanding industrial environments and harsh conditions.
Superior Visual Performance and Display Technology
Equipped with an industrial-grade LCD panel delivering exceptional image quality through wide viewing angles, high brightness output (high nits), and authentic color reproduction. The display maintains optimal visibility across various lighting conditions, from direct sunlight to low-light manufacturing facilities.
Advanced Multi-Touch Capabilities
Features a precision-engineered multi-point PCAP (Projected Capacitive) touchscreen technology, providing exceptional touch sensitivity and instantaneous response times for seamless user interaction and enhanced operational efficiency.
Enterprise-Class Reliability and Performance
Built around a high-performance mainboard architecture designed for continuous 24/7 operation, delivering consistent performance for mission-critical applications requiring uninterrupted uptime.
Extended Temperature Operating Range
Certified for extreme environmental conditions with an operating temperature range of -10°C to 60°C and storage temperature tolerance from -20°C to 70°C, ensuring dependable functionality across diverse geographic locations and seasonal variations.
Versatile Installation Options
Supports multiple mounting configurations including wall-mount, panel-mount (embedded), VESA-compatible mounting, and desktop stand installation, offering flexible deployment solutions for various spatial requirements and industrial applications.
Features
Aluminum alloy case, front IP65 waterproof and dustproof.
Industrial LCD panel, wide viewing angle, high nits, true color.
Adopt multi-points PCAP touch panel, high sensitive and fast-response.
High performance mainboard, 7x24 continuous operation.
Wide temperature range: operating: -10 to 60°C, storage: -20 to 70°C.
Support wall mounting, embedded mounting, desk stand mounting etc.
Specification
| Model:SL900M | |
| LCD panel | |
| Panel size | 10.1" ~ 21.5" |
| Resolution | 1024*768,1280*800,1280*1024,1366*768,1440*900,1920*1080 |
| Aspect ratio | 4:3,5:4,16:9,16:10 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 300 nits |
| Contrast ratio | 1000:1 |
| View angle | 80°/80°/80°/80° (R/L/U/D) |
| Touch panel | |
| Touchscreen Type | Project Capacitive Touch (10 points ) |
| Surface Hardness | 7H |
| Luminousness | 90% |
| Touch Interface | USB (RS232 optional) |
| Touch response time | 2ms |
| Working Life | >50 million times |
| Touch options | (5 wires restive touch, IR touch optional) |
| Signal Ports | |
| VGA | 1x VGA |
| HDMI | 1x HDMI |
| DVI | 1x DVI |
| Audio in/out | optional |
| OSD | |
| OSD control | Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
| Support languages | English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
| Support OS | Windows XP, Windows /7/8/10, Linux, Mac OS X, Android, ect. |
| Power Supply | |
| External Power Supply | AC 100 - 240V, 50-60Hz |
| Working voltage | DC 12V (9-36V DC Optional) |
| Power consumption | ≤15W |
| Enclosure | |
| Material | Aluminum alloy bezel+High strength cold rolled steel back case |
| Color | Black, Silver |
| VESA mounting | 75x75mm |
| IP grade | Front panel IP65 waterproof |
| Operating Environment | |
| Temperature Range | operating: -10 to 60°C, storage: -20 to 70°C |
| Relative humidity | operating: 10% to 80%, storage: 5% to 90% |
| Packing Details | |
| Net weight | 3.35kg |
| Gross weight | 6kg |
| Product Dimension | 420x269x61mm |
| Packing size | 47x44x15cm |
| Accessories | Power adapter, power cord, USB touch cable, HDMI/ VGA cable, embedded screws |
| Other | |
| Mounting | embedded mounting screws |
| wall mounting brackets (optional) | |
| desk stand holder (optional) | |
| Warranty | 1 year warranty |
| Certificates | CE, FCC, RoHS |
Available Sizes:
| Size | Resolution | Aspect ratio | Touch type |
| 10.1" | 1280*800 | 16:10 | capacitive/resistance |
| 12.1" | 1024*768 | 4:3 | capacitive/resistance |
| 15" | 1024*768 | 4:3 | capacitive/resistance |
| 15.6" | 1920*1080 | 16:9 | capacitive/resistance |
| 17" | 1280*1024 | 5:4 | capacitive/resistance |
| 19" | 1280*1024 | 5:4 | capacitive/resistance |
| 21.5" | 1920*1080 | 16:9 | capacitive/resistance |
