Industrial Panel PC SC100M

Quick Details:

CPUIntel Celeron J1900RAM2GB
Hard Drive32G SSDPanel size12"-21.5"
Brightness400nitsView angle80/80/80/80
MaterialAluminum alloyTouch TypeCapacitive touch

Features:

1. Robust all-metal enclosure, shockproof and durable, excellent heat dissipation.

2. Industrial  LCD panel, wide viewing angle, high nits, true color.

3. Adopt 5 wires resistive touch screen, high precision, durable, anti-interference.

4. High performance motherboard, 7x24 continuous operation.

5. Support wall mounting, embedded and rackmount etc. apply to a wide range of industrial application.


Specification:


PC
CPUIntel® Celeron J1900  (I3/I5/I7 optional)
ChipsetIntel ValleyView SSA-CUnit
Memory2G  DDR3, (Max. 8G)
Hard Drive Capacity32G SSD
Hard Drive OptionalSSD: 16GB, 32GB, 64GB, 128GB, 256GB
HDD: 160GB, 320GB, 500GB, 1TB
GraphicsCPU Integrated graphics HD Graphics and support 1080p HD photo quality
AudioRealtek ALC662, High Definition Audio (HD), Line in, Line out
Network1×Realtek RTL 8111E Gigabit Ethernet controller
Wireless NetworkWIFI (Bluetooth, 3G/4G optional)
I/O Interface4×USB, 2 x COM RS232
1×VGA/HDMI/RJ45/Audio OUT/MIC IN/POWER DC
Operation SystemSupport Windows 7/8/10, Linux, Ubuntu, Debian etc.
LCD panel
Panel size12"-21.5"
Support Color16.7M colors
Brightness (cd/m²)400+ nits
Response time5ms
Backlight typeLED
Backlight life time≥50K hours
View angle80°/80°/80°/80° (R/L/U/D)
Touch panel
Touchscreen Type5 wire resistive touch
Touch options10 point capacitive touch
Power Supply
External Power SupplyAC 100 - 240V
Working voltageDC 12V
Enclosure
MaterialHigh strength cold rolled steel
ColorBlack, White, Silver, color can be customized
VESA mounting75×75mm/100×100mm
Operating Environment
Temperature Rangeoperating: -10 to 60°C, storage :-20 to 80°C
Relative humidity5%~95% @ 40° C, non-condensing
Vibration5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
Other
Mounting (options)1) provide wall brackets for wall-mounting, VESA 100×100mm
2) provide stable metal holder to support the monitor
Warranty1 year warranty
AccessoriesPower adapter, embedded screws, warranty card, user manual
CertificatesCE, FCC, RoHS


Product Series:

SizeResolutionAspect ratioTouch type
12"1024*7684:3no touch/capacitive/resistive
15"1024*7684:3no touch/capacitive/resistive
17"1280*10245:4no touch/capacitive/resistive
19"1280*10245:4no touch/capacitive/resistive
19"1440*90016:10no touch/capacitive/resistive
21.5"1920*108016:9no touch/capacitive/resistive
