32 Inch Embedded Touch Panel PC

Quick Details:

CPUCore i3-5005URAM8GB
StorageSSD 256GBPanel size32"
Brightness300 nitsWarranty1 year
MaterialAluminum alloyIP GradeIP65


1. Front bezel aluminum alloy brushed metal craft, front panel IP65 waterproof.

2. Industrial  LCD panel,  wide viewing angle,  high nits, true color.

3. Ultra-thin front bezel 4mm,  ideal for embedded mounting in outdoor kiosk/ parking machine/ charging station and so on.

4. High performance motherboard, 7x24 continuous operation.

5. With fan and distributed cooling vents to improve stability.


CPUIntel Core® i3-5005U, 2.0GHz
Hard Drive Capacity256G SSD
Hard Drive OptionalSSD: 128G, 256GB, 512GB
HDD: 500GB, 1TB
GraphicsIntel® HD Graphics 5500
AudioRealtek ALC662, High Definition Audio (HD), Line in, Line out
Network1xRealtek RTL 8111E Gigabit Ethernet controller
Wireless NetworkWIFI optional
I/O Interface4xUSB, 1xRJ45, 2xRS232
Operation SystemSupport Windows 7/8/10, Linux, Ubuntu, Debian, etc.
LCD panel
Panel size32"
Aspect ratio16:9
Support Color16.7M colors
Brightness (cd/m²)300 nits
Response time5ms
Contrast ratio1000:1
View angle89*°/89°/89°/89° (R/L/U/D)
Power Supply
External Power SupplyAC 100-240V
Working voltageDC 12V
MaterialAluminum Alloy bezel+high strong rolled steel back case
ColorSilver, Black, white, color can be customized
VESA mounting200*200mm
IP gradeFront panel IP65 waterproof
Operating Environment
Temperature RangeOperating: -10 to 60°C, Storage: -20 to 70°C
Relative humidity5%~95% @ 40° C, non-condensing
Vibration5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
Mounting (options)Embedded mounting screws
Wall mounting brackets (optional)
Desk stand holder (optional)
Warranty1 year warranty
CertificateCE, FCC, RoHS
