Full IP65 High Brightness Touch Monitor

Home > Products > Touch Monitor > Full IP65 High Brightness Touch Monitor

  • 24 27 inch Optical Bonding LCD Screen IP67 Metal Monitor 1200 nits
  • 24 27 inch Optical Bonding LCD Screen IP67 Metal Monitor 1200 nits
  • 24 27 inch Optical Bonding LCD Screen IP67 Metal Monitor 1200 nits
  • 24 27 inch Optical Bonding LCD Screen IP67 Metal Monitor 1200 nits
  • 24 27 inch Optical Bonding LCD Screen IP67 Metal Monitor 1200 nits

24 27 inch Optical Bonding LCD Screen IP67 Metal Monitor 1200 nits

Quick Details:

Panel size24" 27"Resolution1920*1080
Aspect ratio16:9InterfaceHDMI
Brightness1200nitsFeaturesAnti Glare
IP GradeFull IP67MaterialMetal Case



Features

1. Robust and durable, all-metal enclosure, sealing design.

2. Full IP67 waterproof, Sealed I/O with cable set included.

3. 24 inch Industrial LCD panel 1200 nits, sunlight readable.

4. With light sensor for auto dimming.

5. With Optical Bonding 3MM Anti-Glare tempered glass.

6. High performance mainboard, 7x24 continuous operation.


Specification

Model:SL24W, SL27W
LCD panel
Panel size24" 27"
Resolution1920*1080
Aspect ratio16:9
Support Color16.7M colors
Brightness (cd/m²)1200 nits, sunlight readable
Brightness controlLight sensor
Contrast ratio1000:1
View angle89°/89°/89°/89° (R/L/U/D)
Singal Ports
HDMI1xHDMI
VGAoptional
DVIoptional
Audio in/outoptional
OSD
OSD controlBrightness, contrast ratio, auto adjustment, H/V position,  language select etc.
Support languagesEnglish, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc.
Support OSWindows XP, Windwows /7/8/10, Linux, Mac OS X, Android, ect.
Power Supply
External Power SupplyAC 100-240V
Working voltageDC 12V
Power consumption≤50W
Enclosure
Materialaluminium alloy front bezel + High strength cold rolled steel back case
ColorBlack, white, Silver, color can be customized
VESA mounting100x100 mm
IP-gradeFull IP67 waterproof
Operating Environment
Temperature Rangeoperating: -20 to 70°C, storage: -30 to 80°C
Relative humidityoperating: 10% to 90%, storage: 5% to 90%
Packing Details
Net weight8 kg(24"), 10.5 kg(27")
Gross weight10 kg(24"), 12.5 kg(27")
Product Dimension58.84x35.56x6.7 cm(24"), 67.7x41.52x6.4 cm(27")
Packing size68x48x19 cm(24"), 81x53x19 cm(27")
AccessoriesPower adapter, Waterproof Power cord, Waterproof HDMI cable
Other
Mounting (options)1) wall brackets for wall-mounting, VESA 100×100 mm
2) stable metal holder to support the monitor
Warranty1 year warranty
