Full IP65 High Brightness Touch Monitor

Home > Products > Touch Monitor > Full IP65 High Brightness Touch Monitor

  • 7 inch Industrial wide temperaturer LCD monitor with remote control
  • 7 inch Industrial wide temperaturer LCD monitor with remote control
  • 7 inch Industrial wide temperaturer LCD monitor with remote control
  • 7 inch Industrial wide temperaturer LCD monitor with remote control
  • 7 inch Industrial wide temperaturer LCD monitor with remote control

7 inch Industrial wide temperaturer LCD monitor with remote control

Quick Details:

Panel size7"Resolution1024*600
Aspect ratio16:9InterfaceHDMI
Brightness1000nitsMaterialAluminium alloy
Touch TypeCapacitiveIP gradeFull IP65 waterproof


Related News




Features


  1. Robust and durable Aluminum alloy bezel and metal back case, full IP65 waterproof.

  2. Industrial wide temperaturer LCD panel, wide viewing angle, high nits, true color.

  3. Adopt multi-points PCAP touch panel, high sensitive and fast-response. Covered with 2mm tempered glass for vandalproof.

  4. EETI waterproof solution, touch function can work well with drop water on the screen.

  5. 1000 nits high brightness, sunlight readable, Anti glare.

  6. High performance mainboard, 7x24 continuous operation.

  7. Wide Temperature Range: operating: -20 to 70°C, storage: -30 to 80°C.

  8. wide voltage: 8-36V.

  9. Function Keys on the bezel, 2 for volume control, 2 for brightness control.

  10. All-in-One cable: HDMI + USB Touch +8-36V DC-IN.


Specification


Model:SL07W
LCD panel
Panel size7"
Resolution1024*600
Aspect ratio16:9
Support Color16.7M colors
Brightness (cd/m²)1000 nits, sunlight readable
Contrast ratio800:1
View angle75°/75°/70°/75° (R/L/U/D)
Touch panel
Touchscreen TypeProject Capacitive Touch (10 points )
Surface Hardness7H
Luminousness90%
Touch InterfaceUSB (RS232 optional)
Touch response time2ms
Working Life>50 million times
Touch options(5 wires restive touch )
Signal Ports
HDMI1x HDMI
VGAoptional
DVIoptional
Audio in/outoptional
OSD
OSD controlBrightness, contrast ratio, auto adjustment, H/V position, language select, etc.
Support languagesEnglish, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc.
Support OSWindows XP, Windows /7/8/10, Linux, Mac OS X, Android, ect.
Power Supply
External Power SupplyAC 100 - 240V
Working voltageDC 8V-36V wide voltage
Power consumption10W
Enclosure
MaterialAluminum alloy bezel+High strength cold rolled steel back case
ColorBlack, Silver
VESA mounting75x75mm
IP gradeFull IP65 waterproof
Operating Environment
Temperature Rangeoperating: -20 to 70°C, storage: -30 to 80°C
Relative humidityoperating: 10% to 80%, storage: 5% to 90%
Packing Details
Net weight1.5kg
Gross weight2kg
Product Dimension20.5*12.5*3.5cm
Packing size29*27*13cm
AccessoriesPower adapter, power cord
Other
Mountingwall mounting brackets (optional)
desk stand holder (optional)
Warranty1 year warranty
CertificatesCE, FCC, RoHS


Sihovision has many years of production experience in the field of industrial computer,our products and services extended gradually from initial industrial automation to commercial smart terminals, intelligent devices, human-machine interface etc.We can provide you perfect ODM/OEM service and after sale service,if you need, welcome to contact us.



7 inch Industrial wide temperaturer LCD monitor with remote control

GPS Plotter monitor , used in navagation

7 inch Industrial wide temperaturer LCD monitor with remote control


7 inch Industrial wide temperaturer LCD monitor with remote control

Request a Quote
For better quotation, pls include:
Size / Application / Quantity / Special requests
