Features
Robust and durable, all-metal enclosure, sealing design, full IP65 waterproof, Sealed I/O with cable set included.
Industrial-grade LCD screen, full viewing angle, 1000 brightness, visible under sunlight, light sensor automatically adjusts brightness, OSD sets 15 steps to adjust brightness, minimum 1~3nits.
10-point capacitive touch screen, the protective layer is 2mm tempered glass (chemically strengthened), the hardness reaches 7H.
Anti-Glare.
Optical bonding.
Use industrial-grade components, work 24/7, and support wide temperature operation -20℃~70℃
Specification
| Model:SL32 | |
| LCD panel | |
| Panel size | 32" |
| Resolution | 3840*2160 4K |
| Aspect ratio | 16:9 |
| Brightness (cd/m²) | 1000 nits sunlight readable |
| Contrast ratio | 3000:1 |
| View angle | 89°/89°/89°/89° (R/L/U/D) |
| Support Color | 16.7M |
| Backlight | WLED, 50K hours |
| Touch panel | |
| Touchscreen Type | Projected Capacitive Touch (up to 10 points ) |
| Surface Hardness | 7H |
| Surface treatment | Anti glare (chemical etching) |
| Luminousness | ≥80% |
| Touch controller IC | EETI 80 |
| Available touch drivers | Windows, Linux, Android, Mac, etc |
| Touch bonding | Optical bonding Bonding |
| Touch options | (5 wires restive touch, IR touch optional) |
| External I/O Ports | |
| Video input | 1xVGA, 1xHDMI |
| Touchscreen interface | 1x USB |
| Power Supply | AC 100-240V |
| Touch OSD | |
| Function Keys | 4 Keys: Up/Down/Menu/Day&Night |
| Menu Functions | Brightness, Contrast, Screen Setting, Color Temp, OSD Language, Auto Adjust, Reset etc. |
| Support languages | English, Français, Español, Português, Deutsch, Italiano, Nederlands, Svenska, Suomi, Polski, čeština, Русский, 한국어,日本語, 繁體中文，简体中文 |
| Enclosure | |
| Material | Aluminium alloy bezel+ Zinc Plating cold rolled steel rear housing |
| Finish | Front bezel: Sandblasting+Hard Anodizing, UV-protection and Anti-discoloration treatment Rear housing: powder coated |
| Color | Black |
| Mounting | VESA mount 100*200mm, Panel mount |
| IP rating | Full IP65 |
| Cooling system | Passive - Fanless |
| Design | 3mm bezel design(open frame design optional) |
| Operating Environment | |
| Temperature Range | Operating: -20 °C ~ 70°C (-4°F ~158°F) Storage: -30 °C~80°C (-22°F ~176°F) |
| Relative humidity | Up to 90% at all relevant temperatures, non-condensing |
| Vibration | GB/T 2423.10-2019 |
| Shock | GB2423.5 |
| EMC | Class B |
| Packing Details | |
| Product Weight | Net weight 18kg |
| Packing info | 1pcs/ctn 98*66*20cm 30kg |
| Accessories | Phoenix conenctors, HDMI cable, DP cable, USB touch cable, Embedded mount screws |
| Other | |
| Warranty | 1 year warranty |
| Certificates | CE, FCC, RoHS |
