ops computer Intel Core 6th 7th 8th CPU Embedded Mini pc

Quick Details:

CPUIntel Skylake-S LGA1151RAM2*DDR4 2133MHz
Hard Drive(ssd)1*M.2 SSD, 1*SATA3.0BIOSAMI 8MB UEFI BIOS
NetworkRealtek 8111FOperation SystemWindows, Linux
MaterialAluminum AlloyPower Supply12V~19v DC-IN



Feature

  1. Intel Celeron j1900, 3865u, core i3 i5 i7 processor-based platform.
  2. Design compliant with OPS (Open Pluggable Standardization).
  3. Supports HDMI, VGA,USB3.0/2.0 via JAE 64-pin connector.
  4. Slot-in integration, easy maintenance.
  5. Supports iManager, SUSIAccess and Embedded Software API.

Specification

Model: SM04
PC
CPU
the 6th Gen. Intel Skylake-S LGA1151 CPU, the 7th Gen. Intel Kabylake-S LGA1151 CPU
Memory
2*DDR4-2133MHz up to 32GB RAM
Storage
1*M.2 SSD or 4G module, 1*SATA3.0
Audio
Realtek HD ALC662 (Line-out,MIC-in)
Ethernet
Realtek 8111F 10/100/1000Mbps
OS
Win7 32/64 bit (only Skylake CPU onboard), Win10 64 bit,Linux 32/64 bit
Expansion
M.2 WIFI, SIM
Interface
DP
1*DP, Max.4096*2304@60Hz
HD-MI
1*HDMI
RJ45
1*RJ45
MIC-IN
1*MIC-IN
LINE-OUT
1*LINE-OUT
COM
1*RS232
USB3.0
2*USB3.0
USB2.0
4*USB2.0
CLR_CMOS
1*CLR_CMOS
OPS 80 JAE
1*OPS 80 JAE
Tact swtich
1*Tact swtich
Other
Power
12V~19v DC-IN
Dimension(mm)
195L x202W x 42.5H mm
Weight
Net weight 1.5kg
Environment
operating temp
-15℃~50℃
Storage temp
-20℃~80℃
Enclosure
Material
Aluminum alloy
Color
Black, Silver, others Optional





Request a Quote
For better quotation, pls include:
Size / Application / Quantity / Special requests
