Features
Full Aluminum alloy enclosure, compact, low weight design, excellent heat dissipation.
Sealed construction full IP67 waterproof, fanless design, noiseless, low-power consumption design.
Suitable for harsh operating environment , dustproof, anti-corrosion, shockproof, anti-vibration.
High performance motherboard, 7x24 continuous operation.
Wide operating temperature support (-20°C~60°C)
With high electromagnetic compatibility and anti-interference capacity.
With 4xPOE waterproof LAN ports.
Specification
| Full IP67 Industrial Mini PC with 4xPOE LAN Ports | |
| PC | |
| CPU | Intel® Core i5-1135G7, quad-core, 8 threads, 2.4GHz, Max Turbo 4.2GHz, fanless |
| Memory | 8G DDR4 (Max 32GB) |
| Hard Drive Capacity | 64G SSD (128GB, 256GB, 512GB SSD optional) |
| Graphics | Intel® Iris® Xe Graphics |
| Network | 5× Intel I211AT, LAN1~4 support POE, IEEE 802.3af standard (Single POE port max power 15.4W, Total power of POE ports not exceeding 45W ) |
| Wireless Network | WIFI+Bluetooth 4.0 |
| Front I/O Ports | 1*HDMI, 1*USB3.0, 1*RJ45, 1*AC in, 1*Power Button |
| Rear I/O Ports | 4*POE |
| Resolution support | Min. 800*600, Max. 4096x2304 |
| Operation System | Support Windows 10, Unix/Linux, Ubuntu, Debian etc. |
| Power Supply | |
| Power input | AC 220V |
| Power consumption | ≤70W |
| Enclosure | |
| Material | Aluminum Alloy |
| Color | Black, Silver , white, color can be customized |
| Operating Environment | |
| Temperature Range | operating: -20 to 60°C, storage : -20 to 70°C |
| Relative humidity | 5%~95% @ 40° C, non-condensing |
| Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
| Packing Details | |
| Net weight | 2.5kg |
| Gross weight | 5kg |
| Product Dimension | 264*186*62.5mm |
| Packing size | 430*380*190mm |
| Accessories | IP67 AC power cord, 5xLAN waterproof cable,1xHDMI/USB waterproof cable, WIFI/4G antenna |
| Other | |
| Mounting (options) | Built-in mounting bracket |
| wall/desking mounting brackets (optional) | |
| Warranty | 1 year warranty |
