Features:
Open side strip installation, no bezel design
Industrial grade LCD screen, full viewing angle
10 point capacitive touch screen, the protective layer is 1.8mm tempered glass (chemically strengthened), the hardness reaches 6H
EETI touch control solution, normal touch when there are water droplets on the touch screen
Use industrial-grade components, work 24/7, and support wide temperature operation -20-70℃
Specification
| Model:SC15 | |
| PC | |
| CPU | Intel® Celeron J4125, Base 2.4 Ghz, Turbo 2.7 Ghz |
| Chipset | Intel® Gemini Lake |
| Memory | 8G DDR4-2400/2133 |
| Storage Capacity | 256G SATA3.0 |
| Graphics | Intel® UHD Graphics 600 |
| Audio | Realtek ALC662, High Definition Audio (HD), Line in, Line out |
| Network | 1*Realtek RTL8106E Gigabit network card |
| Wireless Network | WIFI + Bluetooth 4.0 |
| Preinstalled OS | Window10 Pro |
| Operation System | Support Windows 7/8/10, Linux, Ubuntu, Debian, etc. |
| I/O | |
| USB | 2* USB2.0, 2* USB3.0 |
| COM | 2* COM RS232 |
| LAN | 2* RJ45 |
| Video Outputs | 1*VGA, 1*HDMI |
| Audio | 1* 3.5mm Line-out, 1* 3.5mm Line-in (2 x 2W Speakers) |
| Power input | 1* 12V DC jack |
| Other | 1* Power on/off button, 1* WIFI antenna jack male |
| LCD panel | |
| Screen diagonal | 15" |
| Display active area | 305.1(W)×229.1(H) mm |
| Resolution | 1024*768 |
| Aspect ratio | 4:3 |
| Brightness (cd/m²) | 300 nits |
| Brightness control | N/A |
| Contrast ratio | 1000:1 |
| View angle | 89°/89°/89°/89° (R/L/U/D) |
| Support Color | 16.7M colors |
| Backlight | WLED, 50K hours |
| Touch panel | |
| Touchscreen Type | Projected Capacitive Touch (up to 10 points ) |
| Surface Hardness | 7H |
| Surface treatment | N/A |
| Luminousness | ≥90% |
| Touch controller IC | EETI 80 |
| Available touch drivers | Windows, Linux, Android, Mac, etc |
| Touch bonding | Air bonding |
| Touch optional | Resisive touch, non touch, IR touch optional |
| Power Supply | |
| Working voltage | DC 12V |
| Power consumption | 18W |
| Power adapter | AC 100 ~ 240V input and DC +12V@5A MAX output, 60W |
| Enclosure | |
| Material | Galvanized cold rolled plate shell |
| Finish | Electrostatic powder spraying |
| Color | Silver |
| VESA mounting | VESA mount 75*75/100*100mm, Panel mount |
| IP grade | Front IP65 waterproof |
| Operating Environment | |
| Temperature Range | operating: -20 °C(-4℉) to 70°C(158℉), storage: -30 °C(-22℉) to 80°C(176℉) |
| Relative humidity | Up to 100% at all relevant temperatures, non-condensing |
| Vibration | GB/T 2423.10-2019 |
| Shock | GB2423.5 |
| EMC | Class B |
| Packing Details | |
| Product weight | Net weight 3.5kg Gross weight 5kg |
| Product Dimension | 381×267.2×65mm |
| Packing info | 1pcs/ctn 53×16×40cm 5kg 2pcs/ctn 53×30×40cm 10.5kg |
| Accessories | Power cable, Power supply, Embedded mount screws, Antenna |
| Other | |
| Warranty | 1 year warranty |
| Certificate | CE, FCC, RoHS |
