Feature
Stable performance, lower power consumption.
Intel Celeron 4205U (duad core, 2 threads,1.8GHz).
Intel core i5-8265u (quad core, 8 threads, 1.6 GHz, Max Turbo 3.9 GHz).Intel Core i7-8565u (quad core, 8 threads, 1.6 GHz, Max Turbo 4.1 GHz).
Efficient heat dissipation.
High quality aluminum case forquickly heat dissipation.
Fanless design for dustproof,shockproof and no noise.Fanless design for dustproof,shockproof and no noise.
I/O
(2*COM support RS232/422/485 optional) lt can connect many device, Such as industrial instruments.
Full HD Dual Display
Support synchronous and asynchronous dual display
Various applications
Small PC with high-end configuration.
Specification
| Model: SM3046 | |
| PC | |
| CPU | Onboard Intel Celeron 4205U(Dual core dual threads,1.8Ghz,2MB Cache); |
| Onboard Intel Core i5-8265U(Quad core eight threads,1.6Ghz,Max turbo 3.9Ghz,6MB Cache); | |
| Onboard Intel Core i7-8565U(Quad core eight threads,1.8Ghz,Max turbo 4.6Ghz,8MB Cache); | |
| BIOS | AMI EFI BIOS |
| RAM | Support 1*DDR4 2133/2400 SODIMM Memory slot,Max. Support 32GB |
| Display Chip | Integrated Intel UHD Graphics |
| Display Port | 1*VGA,1*HDMI(Support synchronous and asynchronous dual display) |
| Front I/O | 2*USB2.0,2*COM,1*VGA |
| Rear I/O | 4*Intel 1000M LAN,4*USB3.0,1*HDMI,1*Audio (Support Mic and Speaker at the same time) |
| 2*COM(COM1,COM2 RS232/RS422/RS485 Optional),1*2Pin power supply phoenix connector,1*Power Switch | |
| Support 1*M.2 M-Key 2280 slot(Support SATA Protocol) | |
| Expansion | Support 1*MINI PCIE Slot(WIFI/3G/4G Optional; choose one from three),embedded SIM Slot |
| Expansion Ports:GPIO(8 Input 8 Output),2*COM,1*USB2.0(Standard version doesn’t include these ports) | |
| Network | 4*Intel i211-AT 10/100/1000M LAN |
| Storage | 1*M.2 2280 slot,1*2.5” HDD,Support RAID 0/1 |
| Function | TPM2.0 security encryption,Auto power on when there is electricity,Timing boot,Wake on LAN,PXE boot,Watchdog(0~255 level)(Standard |
| version doesn’t set these function) | |
| Power Supply | |
| Power Supply | DC 9V ~ 36V wide voltage Input,support positive pole and negative electrode connect reversely protection; |
| Enclosure | |
| Case Color | Titanium gray (Color can be customized) |
| Material | Aluminum alloy chassis |
| Operating Environment | |
| Work Temp | 0℃ ~ +50℃(Commercial HDD),-20℃ ~ +60℃(Industrial SSD),Surface air flow |
| Work Humidity | -10°C - 50°C |
| Working Humidity | 5% ~ 95% non-condensing |
| Packing Details | |
| Size | 280*143*40mm |
| Weight | 1.45kg |
| Application | Industrial Automation,Medical,Data Acquisition, Motion Control, Vehicle Applications etc. |
| Other | |
| Mounting (options) | 1) provide wall brackets for wall-mounting, VESA 100×100mm |
| 2) provide stable metal holder to support the monitor | |
| Customization | 3G,4G,Webcam, RFID reader etc. optioanal |
| Warranty | 1 year warranty |
