Features:
1.Enclosed dust-proof,anti-corrosion,anti-vibration,Electromagnetic compatibility and high anti-interference ability.
high reliability, continuous production,decreasing failure rate.
2.The motherboard adopts unique design,(watchdog),remote wakening,automatic reset
3.Aluminum alloy materials, drawing process,heat dissipation,Fanless ,noiseless.
4. High performance motherboard, 7x24 continuous operation. Working temperature:-20° ~65°.
5.Fast Network Connecting: Wireless & Wired Gigabit Lan.
6.Support Industry Standard Software, compatible with Win7\8\10 and Linux.
7.Expandeddisplay for Multi-task ; Electricity Boot.
8.Graphics Processing Ability: Clearer Quality Image and full color.
9.Work well in harsh environment.
Specification:
| Model:SM001 | |
| PC | |
| CPU | Intel® Celeron J1900 , quad core , 2.0GHz, fanless |
| Chipset | Intel ValleyView SSA-CUnit |
| Memory | 2G DDR3 (4G,8G optional) |
| Hard Drive Capacity | 32G SSD |
| Hard Drive Optional | SSD: 64G,128GB,256GB |
| HDD: 500GB,1TB | |
| Graphics | CPU Integrated graphics HD Graphics and support 1080p HD photo quality |
| Audio | Realtek ALC662, High Definition Audio (HD), Line in, Line out |
| Network | 1×Realtek RTL 8111E Gigabit Ethernet controller |
| Wireless Network | WIFI 2.4G (5G/2.4G+Bluetooth 4.0/5G+Bluetooth 4.0 optional) |
| I/O Interface | 5×USB 2.0,1×USB 3.0, 6x COM RS232 |
| 1×VGA/HDMI/RJ45/Audio OUT/MIC IN/POWER DC | |
| Resolution support | above 800*600 |
| Hd support | 1080P |
| Operation System | Support Windows 7/8/10, Linux, Ubuntu, Debian etc. |
| Power Supply | |
| External Power Supply | AC 100 - 240V |
| Working voltage | DC 12V |
| Power consumption | ≤40W |
| Enclosure | |
| Material | Aluminum Alloy Die casting |
| Color | Silver , Black,color can be customized |
| Operating Environment | |
| Temperature Range | operating: -20 to 65°C, storage :-40 to 80°C |
| Relative humidity | 20%~95% , non-condensing |
| Anti-vibration | 5-19HZ / 1.0mm amplitude; 19-200HZ / 1.0g acceleration |
| Impact | 10g acceleration, 11ms cycle |
| Packing Details | |
| Net weight | 2kg |
| Gross weight | 3kg |
| Product Dimension | 19.95*21.31*5.83cm |
| Packing size | 30×31×10 cm |
| Accessories | Power adapter,open frame kits,user manual,warranty card |
| Other | |
| Mounting (options) | open frame |
| wall mounting brackets (optional) | |
| Warranty | 1 year warranty |
