Industrial Android Tablet PC

Home > Products > Industrial Computer > Industrial Android Tablet PC

  • Front 2MP Camera Android 9.0 Panel PC RK3288 4GB RAM 32GB EMMC
  • Front 2MP Camera Android 9.0 Panel PC RK3288 4GB RAM 32GB EMMC
  • Front 2MP Camera Android 9.0 Panel PC RK3288 4GB RAM 32GB EMMC
  • Front 2MP Camera Android 9.0 Panel PC RK3288 4GB RAM 32GB EMMC

Front 2MP Camera Android 9.0 Panel PC RK3288 4GB RAM 32GB EMMC

Quick Details:

CPURK3288RAM4G DDR3
eMMC32GPanel size12.1"
Brightness300 nitsTouch TypeCapacitive
SystemAndroid 9.0IP GradeFront IP65

Features

  1. Fully enclosed design, the whole tablet PC is dustproof.

  2. Seamless design flat bezel, front panel IP65 waterproof.

  3. Aluminum alloy shell, good mechanical properties, excellent heat dissipation.

  4. Industrial LCD panel, wide viewing angle, high nits, true color.

  5. Adopt multi-points PCAP touch panel, high sensitive and fast-response.

  6. Covered with 3mm tempered glass for vandalproof.

  7. High performance motherboard, 7x24 continuous operation.

  8. With wifi, bluetooth. Built in 2MP camera, built in high quality loundspeaker.


Specification


Model: SC121A
PC
CPURK3288, Quad cores
OptionalRK3399, 6 cores
Memory4GB DDR3(2G Optional)
Storage32GB EMMC (8G 16G 64G Optional)
Decoding ResolutionSupport 1080P
Operation SystemAndroid 9.0  (Android1 6.0, 7.1, 8.1 Optional)
Play ModesSupport timing,  loop and spots etc. play modes
Network Support RJ45, WIFI, Bluetooth (3G, 4G, TD-LTE Optional)
Image FormatJPEG/BMP/GIF/PNG
Video FormatRMVB, FLV, MPEG1/2/4, AVI, WMV, MOV, MP4, TS, etc.
Audio FormatMP3, WMA, AAC, etc.
RTC Real Time ClockYES
LoundspeakerHigh quality speaker
CameraBuilt in 2MP camera
I/O Interfaces
USB4xUSB (2USB Optional)
COM2xCOM
LAN1xRJ45, 10M/100M adaptive ethernet
HDMI1xHDMI , support 1080p
DC1xDC, 1xPHOENIX TERMINAL
Type-C1xType-C
Card Slot1xTF card slot
SIM Slot1xSIM slot
Audio I/O1xAudio I/O
Power switch1xPower on/off
LCD panel
Panel size12.1"
Resolution1024*768  (1280*800 Optional)
Aspect ratio4:3
Support Color16.7M colors
Brightness 300 cd/m² (1000 nits Optional)
Response time5ms
Contrast ratio1000:1
View angle85°/85°/85°/85° (R/L/U/D)
Touch panel
Touchscreen Type10 point capacitive touch (5 wire resistive touch/withouth touch Optional)
Touch response time<2ms
Luminousness90%
Surface Hardness7H
Working Life >50 million times
Power Supply
External Power SupplyAC 100 - 240V
Working voltageDC 12V (9-36V DC wide voltage Optional)
Power consumption≤20W
Enclosure
AppearanceFlat panel
MaterialAluminum alloy bezel+ High strength cold rolled steel back case
ColorBlack, Silver, others Optional
VESA mounting75x75mm/100x100mm
IP gradeFront IP65 waterproof
Operating Environment
Working temperature-10°C to 60°C
Storage temperature-20°C to 70°C
Relative humidity5-85% (npn-condensing)
Vibration resistance5-19Hz/1.0mm amplitude, 19-200Hz/1.0g acceleration
Impact resistance10g acceleration, 11ms period
Packing Details
Net weight2.8 kg
Gross weight4 kg
Product dimension326x278x44 mm
Packing size43*41*18cm/1 unit   43*41*35cm/2 units
AccessoriesPower adapter, power cord, embedded screws, WIFI antenna, wall mount bracket
Other
Mounting wayEmbedded mounting screws
Wall mounting brackets (Optional)
Desk stand holder (Optional)
Customization (optional)3G, 4G, Webcam, RFID reader etc. Optional
Warranty1 year warranty




None

None
Request a Quote
For better quotation, pls include:
Size / Application / Quantity / Special requests
