Features
1. Material: 316 Stainless steel. full IP67 waterproof, Sealed I/O with cable set included.
2. Industrial 15.6'' LCD panel, 1920*1080 resolution, wide viewing angle, high nits, true color.
3. High brightness 1000 nits, sunlight readable.
4. with a dimmer for controlling the brightness, can adjust the brightness from 100% to 0.
5. High performance mainboard, 7x24 continuous operation.
6. VGA+HDMI interface.
7. Support wall mounting, embedded mounting, desk stand mouting etc.
Specification
| Model:SL156 | |
| LCD panel | |
| Panel size | 15.6" |
| Resolution | 1920*1080 |
| Aspect ratio | 16:9 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 1000 nits, sunlight readable |
| Brightness control | Manual dimmer |
| Contrast ratio | 1000:1 |
| View angle | 80°/80°/80°/80° (R/L/U/D) |
| Signal Ports | |
| VGA | 1x VGA |
| HDMI | 1x HDMI |
| OSD | |
| OSD control | Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
| Support languages | English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
| Support OS | Windows XP, Windows /7/8/10, Linux, Mac OS X, Android, ect. |
| Power Supply | |
| External Power Supply | AC 100 - 240V, 50-60Hz |
| Working voltage | DC 12V |
| Power consumption | ≤45W |
| Enclosure | |
| Material | 316 Stainless steel |
| Color | Silver |
| VESA mounting | 100x100mm |
| IP grade | Full IP67 waterproof |
| Operating Environment | |
| Temperature Range | operating: -20 to 70°C, storage: -20 to 80°C |
| Relative humidity | operating: 10% to 80%, storage: 5% to 90% |
| Packing Details | |
| Net weight | 5.5 kg |
| Gross weight | 6.5 kg |
| Product Dimension | 40*25.5*5.72cm |
| Packing size | 53*47*19cm |
| Accessories | Power adapter, power cord, HDMI cable, VGA cable |
| Other | |
| Mounting | wall mounting brackets (optional) |
| desk stand holder (optional) | |
| Warranty | 1 year warranty |
| Certificates | CE, FCC, RoHS |
Available Sizes:
| Size | Resolution | Aspect ratio | Touch type |
| 10.1" | 1280*800 | 16:10 | capacitive/resistance |
| 12.1" | 1024*768 | 4:3 | capacitive/resistance |
| 15" | 1024*768 | 4:3 | capacitive/resistance |
| 15.6" | 1920*1080 | 16:9 | capacitive/resistance |
| 17" | 1280*1024 | 5:4 | capacitive/resistance |
| 19" | 1280*1024 | 5:4 | capacitive/resistance |
| 21.5" | 1920*1080 | 16:9 | capacitive/resistance |
| 22" | 1920*1080 | 16:9 | capacitive/resistance |
| 24" | 1920*1080 | 16:9 | capacitive/resistance |
| 27" | 1920*1080 | 16:9 | capacitive/resistance |
Drawing
