Features:
1. Robust and durable aluminium alloy enclosure.
2. Industrial LCD panel, full viewing angle, high nits, true color.
3. Adopt 10 point capacitive touch screen, high precision, durable, anti-interference.
4. High performance motherboard, 7x24 continuous operation.
5. Support wall mounting, embedded and rackmount etc.
6. With wifi, bluetooth. 5 mega-pixel camera, FRID, Fingerprint Reader. loudspeaker.
Specification:
| Model: SC101A | |
| PC | |
| CPU | RK3188, Cortex-A9, quad core, 1.6GHz |
| Memory | 2G, ( Max. 4G) |
| Storage | eMMC 8G, ( Max. 16G) |
| Decoding Resolution | Support maximum 2048*1536 |
| Operation System | Android 4.4.2 |
| Play Modes | Support timing, loop and spots etc. play modes |
| Network Support | RJ45, WIFI, 3G, 4G, TD-LTE (optional) |
| Image Format | JPG/BMP/GIF/TIFF/PNG |
| Video Format | RMVB, FLV, MPEG1/2/4, AVI, WMV, MOV, MP4, TS etc. |
| Audio Format | MP3, WMA, AAC, etc. |
| RTC Real Time Clock | YES |
| I/O Interfaces | |
| USB | 2×USB ( up to 5 ) |
| COM | 2×COM |
| LAN | 1×RJ45, 10M/100M adaptive ethernet |
| DC | 1×DC |
| Card Slot | 1×TF |
| LCD panel | |
| Panel size | 10.1" |
| Resolution | 1366*768 |
| Aspect ratio | 16:9 |
| Support Color | 16.7M colors |
| Brightness | 400 cd/m² |
| Response time | 5ms |
| Contrast ratio | 800:1 |
| View angle | 89°/89°/89°/89° (R/L/U/D) |
| Touch panel | |
| Touchscreen Type | 10 point capacitive touch |
| Touch response time | <2ms |
| Luminousness | 90% |
| Surface Hardness | 7H |
| Working Life | >50 million times |
| Power Supply | |
| External Power Supply | AC 100 - 240V |
| Working voltage | DC 12V |
| Power consumption | ≤45W |
| Enclosure | |
| Material | Aluminum alloy |
| Color | Black, white, Silver, color can be customized |
| VESA mounting | 75×75mm/100×100mm |
| Operating Environment | |
| Working temperature | -10°C to 55°C |
| Relative humidity | <85% |
| Vibration resistance | 5-19Hz/1.0mm amplitude, 19-200Hz/1.0g acceleration |
| Impact resistance | 10g acceleration, 11ms period |
| Packing Details | |
| Net weight | 3.5 kg |
| Gross weight | 4 kg |
| Product Dimension | 46×32×7.1cm |
| Packing size | 47×43×18 cm |
| Accessories | Power adapter, embedded screws, warranty card, user manual |
| Other | |
| Customization | 5 mega-pixel camera |
| FRID | |
| Fingerprint Reader | |
| loudspeaker | |
| Mounting (options) | 1) provide wall brackets for wall-mounting, VESA 100×100mm |
| 2) provide stable metal holder to support the monitor | |
| Customization | 3G, 4G, Webcam, RFID reader etc. optioanal |
| Warranty | 1 year warranty |
Available Sizes:
| Size | Resolution | Aspect ratio | Touch type |
| 10.1" | 1280*800 | 16:10 | capacitive/resistance |
| 12.1" | 1024*768 | 4:3 | capacitive/resistance |
| 15" | 1024*768 | 4:3 | capacitive/resistance |
| 15.6" | 1920*1080 | 16:9 | capacitive/resistance |
| 17" | 1280*1024 | 5:4 | capacitive/resistance |
| 19" | 1280*1024 | 5:4 | capacitive/resistance |
| 21.5" | 1920*1080 | 16:9 | capacitive/resistance |
| 22" | 1920*1080 | 16:9 | capacitive/resistance |
| 24" | 1920*1080 | 16:9 | capacitive/resistance |
| 27" | 1920*1080 | 16:9 | capacitive/resistance |
