Uncompromising Durability
With full IP67 certification, this monitor offers complete protection against water immersion and dust ingress. Whether facing saltwater spray, heavy rain, or dusty industrial conditions, the SL700W-4k continues operating reliably. The robust construction features an aluminum alloy bezel with hard anodizing and UV-protection treatment, while the zinc-plated cold-rolled steel housing ensures long-term corrosion resistance.
Exceptional Visual Performance
Equipped with a 1300 nits Mini LED backlight and automatic light sensing, this display remains perfectly visible in any lighting condition—from the brightest tropical sun to nighttime operation. The stunning 4K UHD resolution (3840×2160) with 255 PPI delivers razor-sharp detail, while the impressive 12000:1 contrast ratio and 95% DCI-P3 color gamut ensure rich, accurate colors. Optical bonding technology eliminates internal condensation and fogging while dramatically improving readability and durability.
Advanced Touch Technology
The 10-point PCAP touch panel features 2mm chemically strengthened tempered glass with 7H surface hardness, providing scratch resistance and durability. EETI's waterproof touch solution includes an innovative ON/OFF control button that prevents false touches from waves, rain, or water splashes. The anti-glare surface treatment through chemical etching reduces ambient reflections without compromising touch sensitivity.
Smart Design Features
· Touch-sensitive OSD buttons with automatic security lock after 1 minute
· Fanless passive cooling system for silent, maintenance-free operation
· Extended temperature range: -20°C to 70°C operating
· 100% relative humidity tolerance (non-condensing)
· Waterproof connections for HDMI, USB, and power
· Garmin MFD compatibility for seamless navigation integration
· IP67 breather valve maintains pressure equalization
Reliable and Versatile
With wide 9-36V DC input voltage and surge protection, this monitor adapts to various power systems. The fanless design eliminates moving parts for enhanced reliability and reduced maintenance. Universal driver support ensures compatibility with Windows, Linux, Android, and Mac operating systems.
Built for professionals who demand uncompromising performance in the harshest environments, the SL700W-4k delivers exceptional value with industrial-grade reliability, premium visual quality, and comprehensive environmental protection.
IP67 Touch Screen Marine Monitor Specification
| LCD panel | |
| Panel size | 17.3" |
| Resolution | 3840×2160 |
| Aspect ratio | 16: 9 |
| Brightness (cd/m²) | 1300 cd/m² |
| Brightness control | Automatic light sensing, OSD, (Optional dimming knob) |
| Contrast ratio | 12000:1 |
| View angle | 85°/85°/85°/85° (R/L/U/D) |
| Support Color | 16.7M 95% DCI-P3 |
| Backlight | Mini LED , 30K hours , With LED Driver |
| Touch panel | |
| Touchscreen Type | 10 point capacitive touch |
| Surface Hardness | 7H |
| Surface treatment | Anti glare (chemical etching) |
| Luminousness | ≥ 85% |
| Touch controller IC | EETI80 |
| Available touch drivers | Windows, Linux, Android, Mac, etc |
| Touch bonding | Optical Bonding |
| External I/O Ports | |
| Video input | 1 x IP67 M20 HDMI |
| Touchscreen interface | 1 x IP67 M20 USB-A |
| Power connector | 1 x IP67 M20 DC 9-36V |
| Other | 1 x IP67 Breather valve, 1 x IP67 Touch ON/OFF Button, |
| 1 x GND Point | |
| Power Supply | |
| Working voltage | DC 9 ~ 36V |
| Power adapter | AC 100 ~ 240V input and DC 12V@8A, Max output 96W |
| OSD | |
| Function Keys | 5 Keys: Power/Menu/Up/Down/Return |
| Menu Functions | Brightness, Contrast, Screen Setting, Color Temp, |
| OSD Language, Auto Adjust, Reset etc. | |
| Support languages | English, Français, Español, Português, Deutsch, Italiano,Nederlands, Svenska, Suomi, Polski, čeština, Русский, 한국어,日本語, 繁體中文，简体中文 |
| Enclosure | |
| Material | Aluminium alloy bezel+ Zinc Plating cold rolled steel rear housing |
| Finish | Front bezel: Sandblasting+Hard Anodizing, |
| UV-protection and Anti-discoloration treatment | |
| Rear housing: powder coated | |
| Color | Black |
| Mounting | Stand |
| IP rating | Full IP67 waterproof |
| Cooling system | Passive - Fanless |
| Operating Environment | |
| Temperature Range | Operating: -20 °C ~ 70°C Storage: -30 °C ~ 80°C |
| Relative humidity | Up to 100% at all relevant temperatures, non-condensing |
| Vibration | GB/T 2423.10-2019 |
| Shock | GB2423.5 |
| EMC | Class B |
| Other | |
| Warranty | 1 year warranty |
| Certificates | CE, FCC, RoHS |
| Accessories | 5M power supply, DC cable, 5M Waterproof Micro USB cable, 5M Water proof HDMI cabled |
17.3" Marine Monitor
From factory floors to outdoor installations, these displays serve as reliable human-machine interfaces in a wide range of applications.
Waterproof & Washdown Applications
In food processing plants, beverage production lines, and pharmaceutical facilities, IP65/IP67 waterproof touch monitors are commonly installed near machinery and control stations. These environments require frequent washdown, exposure to moisture, steam, and cleaning chemicals.
Industrial panel PCs with sealed enclosures ensure uninterrupted operation during cleaning processes. The waterproof touch screen remains responsive even when exposed to water, making it suitable for production monitoring, parameter adjustment, and real-time data visualization.
Outdoor Applications
For outdoor use, high-brightness industrial touch monitors are essential to maintain readability under direct sunlight and changing weather conditions. The images show applications such as parking management systems, charging stations, outdoor kiosks, and access control terminals.
With rugged housing and wide temperature tolerance, outdoor industrial panel PCs support long-term operation in rain, dust, and extreme temperatures. These systems are commonly used in smart cities, transportation hubs, and public infrastructure projects.
Embedded & Industrial Automation Applications
In manufacturing environments, embedded industrial panel PCs are integrated directly into machines, production lines, and control cabinets. CNC machines, packaging equipment, and automated assembly lines rely on stable touch monitors for operator interaction and system feedback.
These industrial touch monitors act as the visual control layer for PLC systems, MES platforms, and industrial software, ensuring smooth communication between operators and machines.
Military & Medical Applications
For military command systems and medical environments, reliability and precision are critical. The images demonstrate how rugged industrial panel PCs are used in command centers, vehicle-mounted systems, medical imaging stations, and operating rooms.
In medical settings, touch monitors are designed for easy cleaning and continuous operation, supporting diagnostics, patient monitoring, and surgical assistance. In military applications, rugged displays ensure performance under vibration, shock, and harsh operating conditions.
Vehicle & Kiosk Applications
Industrial touch monitors are also widely used in vehicles, logistics equipment, and self-service kiosks. Applications include train control cabins, forklifts, airport kiosks, ticketing systems, and interactive information terminals.
Vehicle-mounted industrial panel PCs provide real-time operational data, navigation, and system control. Kiosk applications benefit from durable touch screens designed for high-frequency public use and long service life.
Across all these scenarios, industrial panel PCs and IP-rated touch monitors provide a stable and reliable display solution where consumer-grade screens cannot perform. Whether for waterproof environments, outdoor installations, embedded automation, or mobile systems, these industrial displays are designed to support continuous operation and demanding usage conditions.
